NINTENDO GAMECUBE System SpecificationsMPU ('Microprocessor Unit') | Custom IBM Power PC 'Gekko' | | Manufacturing process | : | 0.18 micron IBM copper wire technology | | Clock frequency | : | 485 MHz | | CPU capacity | : | 1125 Dmips (Dhrystone 2.1) | | Internal data precision | : | 32-bit Integer & 64-bit floating-point | | External bus | : | 1.3GB/second peak bandwidth
(32-bit address space, 64-bit data bus 162 MHz clock) | | Internal cache | : | L1: instruction 32KB, data 32KB (8 way)
L2: 256KB (2 way) | System LSI : Custom ATI/Nintendo 'Flipper' | | Manufacturing process | : | 0.18 micron NEC Embedded DRAM Process | | Clock frequency | : | 162 MHz | | Embedded frame buffer | : | Approx. 2MB
sustainable latency : 6.2ns (1T-SRAM) | | Embedded texture cache | : | Approx. 1MB
sustainable latency : 6.2ns (1T-SRAM) | | Texture read bandwidth | : | 10.4GB/second (Peak) | | Main memory bandwidth | : | 2.6GB/second (Peak) | | Pixel depth | : | 24-bit color, 24-bit Z buffer | | Image processing functions | : | Fog, subpixel anti-aliasing,
8 hardware lights, alpha blending,
virtual texture design, multi-texturing,
bump mapping, environment mapping, MIP mapping,
bilinear filtering, trilinear filtering, anisotropic filtering,
real-time hardware texture decompression (S3TC),
real-time decompression of display list,
HW 3-line deflickering filter.
| | Sound Processor | : | custom Macronix 16-bit DSP | | DSP Instruction Memory | : | 8KB RAM + 8KB ROM | | DSP Data Memory | : | 8KB RAM + 4KB ROM | | DSP Clock Frequency | : | 81 MHz | | Performance | : | 64 simultaneous channels, ADPCM encoding | | Sampling Frequency | : | 48KHz |
System Floating-point Arithmetic Capability | | 10.5 GFLOPS (Peak) (MPU, Geometry Engine, HW Lighting Total) |
Real-world polygon | 6 million to 12 million polygons/second (Peak)
(Assuming actual game conditions with complex models, fully textured, fully lit, etc.) |
System Memory (Total 40MB) | Main Memory 'Splash' | | 24 MB MoSys 1T-SRAM, Approximately 10ns Sustainable Latency | A-Memory | | 16 MB (81MHz DRAM) |
Disc Drive | CAV (Constant Angular Velocity) System
Average Access Time : 128ms
Data Transfer Speed : 16Mbps to 25Mbps
| Media | 3 inch NINTENDO GAMECUBE Disc based on Matsushita's Optical Disc Technology,
Approx. 1.5GB Capacity
|
Input/Output | Controller Port x4
Memory Card Slot x2
Analog AV Output x1
Digital AV Output x1
High-Speed Serial Port x2
High-Speed Parallel Port x1
|
|
